186

JELD-WEN.COM

Smooth-Pro Fiberglass ADA Doors (SP)

8'0" = 95"

Door Series

Width

Height Panel

Width

Outer Stiles

Center

Mullion Top Rail Lock

Rail

Bottom

Rail

2-Panel Square Top

SP8-21-ADA

2'8", 2'10", 3'0"

8'0" 23-1/8"

4-5/16", 5-5/16", 6-5/16"

N/A 5-3/8" 6-5/8" 10-1/8"

2-Panel Plank Arch Top

SP8-24-ADA

2'10", 3'0"

8'0" 23-1/8"

5-5/16", 6-5/16"

N/A 5-3/8" 7-5/8" 10-1/8"

6-Panel

SP8-60-ADA

2'8", 2'10", 3'0"

8'0" 9-1/8"

4-5/16", 5-5/16", 6-5/16"

4-7/8" 5-3/8" 6-5/8" 10-1/8"

JELD-WEN, inc. reserves the right to change specifications without notice.

Smooth-Pro Fiberglass Direct Glaze Sidelights (SP-DG)

6'8" = 79"; 7'0" = 83"; 8'0" = 95"

Sidelight Series

Width

Height Panel

Width

Outer Stiles

Center

Mullion Top Rail Lock

Rail

Bottom

Rail

Full View

SP-690DG

1'0", 1'2"

6'8" N/A

1-3/4", 2 3/4"

N/A 5-3/8" N/A 10-3/8"

SP7-690DG

1'0", 1'2"

7'0" N/A

1-3/4", 2 3/4"

N/A 6-7/8" N/A 12-7/8"

SP8-690DG

1'0", 1'2"

8'0" N/A

1-3/4", 2 3/4"

N/A 5-3/8" N/A 10-3/8"

3/4 View

SP-422DG

1'0", 1'2"

6'8" 8-3/8"

1-3/4", 2 3/4"

N/A 5-1/8" 3-15/16" 8-9/16"

SP7-422DG

1'0", 1'2"

7'0" 8-3/8"

1-3/4", 2 3/4"

N/A 6-5/8" 3-15/16" 11-1/16"

SP8-422DG

1'0", 1'2"

8'0" 8-3/8"

1-3/4", 2 3/4"

5-1/8" 4-5/16" 8-3/4"

1/2 View

SP-692DG

1'0", 1'2"

6'8" 8-3/8"

1-3/4", 2 3/4"

N/A 5-1/4" 6-3/8" 8-1/2"

SP7-692DG

1'0", 1'2"

7'0" 8-3/8"

1-3/4", 2 3/4"

N/A 6-3/4" 6-3/8" 11"

Craftsman

SPC-820DG

1'0", 1'2"

6'8" 8-1/4"

1-13/16", 2-13/16"

N/A 5-3/8"

6" 8-9/16"

SPC7-820DG

1'0", 1'2"

7'0" 8-1/4"

1-13/16", 2-13/16"

N/A 6-7/8"

6" 11-1/16"

SPC8-820DG

1'0", 1'2"

8'0" 8-1/4"

1-13/16", 2-13/16"

5-3/8"

6" 8-9/16"

Beadboard

SPB-820DG

1'0", 1'2"

6'8" 8-5/8"

1-5/8", 2-5/8"

N/A 5-3/8" 5-5/8" 8-9/16"

SPB7-820DG

1'0", 1'2"

7'0" 8-5/8"

1-5/8", 2-5/8"

N/A 6-7/8" 5-5/8" 11-1/16"

SPB8-820DG

1'0", 1'2"

6'8" 8-5/8"

1-5/8", 2-5/8"

N/A 5-3/8" 5-5/8" 8-9/16"

Steel Doors - Contours (CT), Contours Flat (CF) Gladiator (GL)

Door Series

Width

Height

Panel

Width

Outer Stiles

Center

Mullion

Top Rail

Lock

Rail

Bottom

Rail

Contours

1-Panel Eyebrow

CT-11

3'0"

6'8"

23

"

6-3/8

"

N/A

5"

N/A 7-7/8"

Contours

1-Panel Flat

CF-10

2'8", 2'10", 3'0" 6'8" 22-15/16

"

4-3/8

",

5-3/8

",

6-3/8"

N/A

5-1/8"

N/A 8-7/8"

Contours

1-Panel Diamond Plate

CT-10D

2'8", 2'10", 3'0" 6'8" 22-15/16

"

4-3/8

",

5-3/8

",

6-3/8"

N/A

5-1/8"

N/A 8-3/4"

Contours

2-Panel Arch Top

CT-20

2'8", 3'0"

6'8"

23

"

4-3/8

",

6-3/8

"

N/A

5"

6-1/2"

9"

Contours

2-Panel Square Top

CT-21

2'8", 3'0"

6'8"

23

"

4-3/8

",

6-3/8

"

N/A

5-3/8

"

6-1/2"

9"

Contours

2-Panel Arch Top Plank

CT-24

2'8", 3'0"

6'8"

23

"

4-3/8

",

6-3/8

"

N/A

5"

6-1/2"

9"

Contours

2-Panel Flat

CF-20

2'8", 2'10", 3'0" 6'8" 22-15/16

"

4-3/8

",

5-3/8

",

6-3/8"

N/A

5-1/8"

6-1/2" 8-7/8"

Contours

3-Panel 3/4 Oval

CT-30/949

2'8", 3'0"

6'8"

10"

4-3/8

",

6-3/8

"

3"

4-5/8"

3-1/2" 6-7/8"

Contours

3-Panel Flat

CF-30

2'8", 2'10", 3'0" 6'8"

Top: 23"

Bottom: 9"

4-3/8

",

5-3/8

",

6-3/8"

N/A

5-1/8"

N/A 8-7/8"

Contours

4-Panel

CT-40

2'8", 3'0"

6'8"

9"

4-3/8

",

6-3/8"

5"

6-1/4"

8"

7-7/8"

Contours

4-Panel With Camber Top or Sunburst

CT-648/659

2'8", 3'0"

6'8" 9-1/16"

4-3/8

",

6-3/8

4-7/8"

20-9/16", 5-1/8"

with cut out

6-3/8" 9-1/16"

Contours

6-Panel

CT-60

2'6"

6'8" 8-5/16"

4-7/16"

4-1/4"

5-1/8"

6-3/8"

9"

CT-60

2'8", 3'0"

6'8"

9"

4-3/8", 6-3/8"

4-7/8"

5-1/8"

6-3/8"

9"

CT-60

3'6"

6'8" 9-1/16"

9-3/8"

4-7/8"

5-1/8"

6-3/8"

9"

CT8-60

2'6"

8'0" 8-5/16"

4-3/8"

4-3/8"

5-1/4"

8" 12-1/4"

CT8-60

2'8", 3'0"

8'0" 9-1/16"

4-3/8"

4-3/8", 6-3/8"

5-1/4"

8" 12-1/4"

Contours

2-Panel 1/2 View

CT-684

2'6"

6'8"

8-3/8

"

4-3/8"

4-1/4"

5-1/8"

6-3/8"

9"

CT-684

2'8", 3'0"

6'8" 9-1/16"

4-3/8

",

6-3/8"

4-7/8"

5-1/8"

6-3/8"

9"

Contours

2-Panel 3/4 View

CT-607

2'8", 3'0"

6'8"

9"

4-3/8

",

6-3/8

"

5"

5-1/8"

4-1/2" 8-3/8"

Contours

Full View

CT-686

2'6"

6'8"

N/A

4-3/8

"

N/A

5-1/8"

N/A 8-7/8"

CT-686

2'8", 3'0"

6'8"

N/A

4-3/8

",

6-3/8

"

N/A

5-1/8"

N/A 8-7/8"

CT8-686

2'6"

8'0"

N/A

4-3/8

"

N/A

5-1/4"

N/A 8-3/4"

CT8-686

2'8", 3'0"

8'0"

N/A

4-3/8

",

6-3/8"

N/A

5-1/4"

N/A 8-3/4"

DOOR & SIDELIGHT

SPECIFICATIONS

FIBERGLASS / STEEL DOOR & SIDELIGHT SPECIFICATIONS

Camber Top and Sunburst designs may have different top rail dimensions than listed above.
