JELD-WEN, inc. reserves the right to change specifications without notice.
Smooth-Pro Fiberglass Doors (SP)
Continued
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
Twin 1/2 View
SP-692
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8"
5"
6-1/8" 8-1/2"
1/2 View - 2-Panel
SP-684
2'6"
6'8" 8-5/16"
4-7/16"
4-7/8"
5"
6-1/8" 8-1/2"
SP-684
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8"
5"
6-1/8" 8-1/2"
SP7-684
2'8", 2'10", 3'0"
7'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 6-1/2" 6-1/8" 11"
SP8-684
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-15/16" 6-3/16" 8-1/2"
1/2 View 1-Panel
SP-684-1P
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A
5"
6-1/8" 8-1/2"
SP7-684-1P
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-1/2" 6-1/8" 11"
SP8-684-1P
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 6-3/16" 8-1/2"
1/2 View 1-Panel Plank
SP-684-1PL
2'10", 3'0"
6'8" 23-1/8"
5-5/16", 6-5/16"
N/A
5"
6-1/8" 8-1/2"
SP7-684-1PL
2'10", 3'0"
7'0" 23-1/8"
5-5/16", 6-5/16"
N/A 6-1/2" 6-1/8" 11"
SP8-684-1PL
2'10", 3'0"
8'0" 23-1/8"
5-5/16", 6-5/16"
N/A 4-15/16" 7-3/16" 8-1/2"
3/4 View 2-Panel
SP-607
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 5-1/2" 4-1/8" 8-1/2"
3/4 View 1-Panel
SP-607-1P
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 3-11/16" 8-1/2"
SP8-607-1P
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 4-1/16" 8-5/8"
Full Oval
SP-919
2'8", 2'10", 3'0"
6'8" N/A
4-13/16", 5-13/16", 6-13/16"
N/A 8-7/8" N/A 11-7/8"
SP7-919
2'8", 2'10", 3'0"
7'0" N/A
4-13/16", 5-13/16", 6-13/16"
N/A 10-3/8" N/A 14-3/8"
SP8-919
2'8", 2'10", 3'0"
8'0" N/A
4-13/16", 5-13/16", 6-13/16"
N/A 16-7/8 N/A 19-7/8"
Full View
SP-686
2'6",2'8", 2'10", 3'0"
6'8" N/A 3-15/16", 3-15/16", 4-15/16", 5-15/16" N/A
5"
N/A 8-1/8"
SP7-686
2'6",2'8", 2'10", 3'0"
7'0" N/A 3-15/16", 3-15/16", 4-15/16", 5-15/16" N/A 6-1/2" N/A 10-5/8"
SP8-686
2'6",2'8", 2'10", 3'0"
8'0" N/A 3-13/16", 3-13/16", 4-13/16", 5-13/16" N/A 4-7/8" N/A
8"
Smooth-Pro Fiberglass Sidelights (SP)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Sidelight Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
Full View
SP-690
10", 1'0'', 1'2''
6'8''
N/A
1", 1-1/2", 2-1/2"
N/A
5"
N/A 8-1/8"
SP7-690
10", 1'0'', 1'2''
7'0" N/A
1-1/2", 2-1/2"
N/A 6-1/2" N/A 10-5/8"
SP8-690
1'0'', 1'2''
8'0''
N/A
7/8", 1-7/8"
N/A 4-7/8" N/A
8"
3/4 View
SP-422
1'0'', 1'2''
6'8''
9-1/2"
1", 2"
N/A 4-15/16" 3-11/16" 8-1/2"
SP8-422
1'0'', 1'2''
8'0" 9-1/8"
1-1/2", 2-1/2"
N/A 4-15/16" 4-1/16" 8-5/8"
1/2 View
SP-692
1'0'', 1'2''
6'8''
9-1/8"
1", 2"
N/A 10-7/16" 6-9/16" 8-1/2"
SP7-692
1'0'', 1'2''
7'0" 9-1/8"
1", 2"
N/A 6-15/16" 6-9/16" 11"
SP8-692
1'0", 1'2"
8'0" 9-1/8"
1", 2"
N/A 4-15/16" 6-3/16" 8-1/2"
Craftsman
SPC-820
1'0", 1'2"
6'8" 8-1/4"
1-13/16", 2-13/16"
N/A 5-3/8"
6" 8-9/16"
SPC7-820
1'0", 1'2"
7'0" 8-1/4"
1-13/16", 2-13/16"
N/A 6-7/8"
6" 11-1/16"
Craftsman Full View
SPC-819
1'0", 1'2"
6'8" N/A
1-15/16", 2-15/16"
N/A 5-1/2" N/A 8-1/2"
SPC7-819
1'0", 1'2"
7'0" N/A
1-15/16", 2-15/16"
N/A 6-7/8" N/A 11-1/8"
Smooth-Pro Fiberglass Direct Glaze Doors (SP-DG)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
Craftsman Direct Glaze
SPC-866DG
2'8", 2'10", 3'0"
6'8" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
SPC7-866DG
2'8", 2'10", 3'0"
7'0" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 6-7/8"
6" 11-1/16"
SPC8-866DG
2'8", 2'10", 3'0"
8'0" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
Beadboard Direct Glaze
SPB-866DG
2'8", 2'10", 3'0"
6'8" 23-5/8"
4-1/16", 5-1/16", 6-1/16"
N/A 5-3/8" 5-5/8" 8-9/16"
SPB7-866DG
2'8", 2'10", 3'0"
7'0" 23-5/8"
4-1/16", 5-1/16", 6-1/16"
N/A 6-7/8" 5-5/8" 11-1/16"
SPB8-866DG
2'8", 2'10", 3'0"
8'0" 23-5/8"
4-1/16", 5-1/16", 6-1/16"
N/A 5-3/8" 5-5/8" 8-9/16"
1/2 View
SP-684DG
2'8", 2'10", 3'0"
6'8" 9-1/4"
4-3/16", 5-3/16", 6-3/16"
4-7/8" 5-1/4" 6-3/8" 8-1/2"
SP7-684DG
2'8", 2'10", 3'0"
7'0" 9-1/4"
4-3/16", 5-3/16", 6-3/16"
4-7/8" 6-3/4" 6-3/8" 11"
3/4 View 1-Panel
SP-607DG-1P
2'6", 2'8", 2'10", 3'0"
6'8" 23-3/8"
4-3/16", 5-3/16", 5-3/16", 6-3/16"
N/A 5-1/8" 3-15/16" 8-9/16"
SP7-607DG-1P
2'6", 2'8", 2'10", 3'0"
7'0" 23-3/8"
4-3/16", 5-3/16", 5-3/16", 6-3/16"
N/A 6-5/8" 3-15/16" 11-1/16"
SP8-607DG-1P
2'6", 2'8", 2'10", 3'0"
8'0" 23-3/8"
4-3/16", 5-3/16", 5-3/16", 6-3/16"
N/A 5-1/8" 4-5/16" 8-3/4"
Full View
SP-686DG
2'0", 2'4", 2'6", 2'8", 2'10", 3'0" 6'8" N/A 5-1/4", 4-1/4", 5-1/4" ,5-1/4",4-3/4", 5-3/4" N/A 5-3/8" N/A 10-3/8"
SP7-686DG
2'0", 2'4", 2'6", 2'8", 2'10", 3'0" 7'0" N/A 5-1/4", 4-1/4", 5-1/4" ,5-1/4",4-3/4", 5-3/4" N/A 6-7/8" N/A 12-7/8"
SP8-686DG
2'6", 2'8", 2'10", 3'0"
8'0" N/A
4-1/4", 5-1/4", 4-3/4", 5-3/4"
N/A 5-3/8" N/A 10-3/8"
DOOR & SIDELIGHT
SPECIFICATIONS
FIBERGLASS DOOR & SIDELIGHT SPECI FICATIONS
