Steel Doors - Contours (CT), Gladiator (GL)
Continued
Door Series
Width
Height
Panel
Width
Outer Stiles
Center
Mullion
Top Rail
Lock
Rail
Bottom
Rail
Contours
™
Full Oval
CT-919
2'8"
6'8"
N/A
4-13/16"
N/A
9-3/4"
N/A 11"
CT-919
3'0"
6'8"
N/A
6-13/16"
N/A
9-13/16"
N/A 11"
Contours
™
8-Panel Center Arch
CT-80/632
2'8", 3'0"
6'8"
*
4-3/8
",
6-3/8"
N/A
5-1/8"
N/A 8-7/16"
Contours
™
9-Panel
CT-90/640
2'8", 3'0"
6'8"
*
4-3/8
",
6-3/8"
N/A
5-1/8"
N/A
8"
Craftsman 3-Panel
CC-30/866
2'6"
6'8"
8-1/4
"
4-13/32
"
4-7/16
"
5-1/8
"
N/A 8-3/8
"
CC-30/866
2'8", 2'10", 3'0"
6'8" 9
",
9
",
10"
4-3/8
",
5-3/8
",
4-7/8
"
5
"
5-1/8
"
N/A 8-3/8
"
Gladiator 4-Panel with Camber Top or Sunburst
♣
GL-648/659
2'8", 3'0"
6'8" 9-1/16"
4-3/8
",
6-3/8
"
4-7/8"
20-11/16",
5-1/8"with cut out
6-3/8"
9"
Gladiator 6-Panel
GL-60
2'6"
6'8" 8-5/16"
4-3/8"
4-3/8"
5-1/8"
6-3/8"
9"
GL-60
2'8", 3'0"
6'8" 9-1/16"
4-3/8
",
6-3/8
"
4-7/8"
5-1/8"
6-3/8"
9"
Steel Sidelights - Contours (CT), Gladiator (GL)
Sidelight Series
Width
Height
Panel
Width
Outer Stiles
Center
Mullion
Top Rail
Lock
Rail
Bottom
Rail
1/2 View
CT-692
1'0", 1'2"
6'8"
9"
1-3/8", 2-3/8"
N/A
5-1/8"
N/A 8-7/8"
GL-692
1'0", 1'2"
6'8"
9"
1-3/8", 2-3/8"
N/A
5-1/8"
N/A 8-7/8"
3/4 View
CT-422
1'0", 1'2"
6'8"
9"
1-3/8", 2-3/8"
N/A
5-1/8"
N/A 8-3/8"
Full View
CT-690
10", 1'0", 1'2"
6'8"
N/A
7/8", 1-3/8", 2-3/8"
N/A
5"
N/A
9"
GL-690
1'0", 1'2"
6'8"
N/A
1-3/8", 2-3/8"
N/A
5"
N/A
9"
CT8-690
1'0", 1'2"
8'0"
N/A
1-3/8", 2-3/8"
N/A
5"
N/A
9"
JELD-WEN, inc. reserves the right to change specifications without notice.
DOOR & SIDELIGHT
SPECIFICATIONS
STEEL DOOR & SIDELIGHT SPECIFICATIONS / ROUGH OPENINGS & UNIT DIMENSIONS
ROUGH OPENINGS & UNIT DIMENSIONS
INSWING DOOR SYSTEM - STANDARD ALUMINUM SILL
– Oak & Mahogany Sill - ADD 1/2" to Height of all dimensions – Public Access Aluminum Sill - Deduct 1" from Height of all dimensions
Size
Rough Opening
Unit Dimension
No Casing
Unit Dimension
w/ Brickmould
Unit Dimension
w/ 1-1/16" x3-1/2"
Flat Casing
2-6 x 6-8
32 1/2
x 82 1/2
31 3/8
x 81 3/4
34
x 83
37
x 84 1/2
2-8 x 6-8
34 1/2
x 82 1/2
33 3/8
x 81 3/4
36
x 83
39
x 84 1/2
3-0 x 6-8
38 1/2
x 82 1/2
37 3/8
x 81 3/4
40
x 83
43
x 84 1/2
5-0 x 6-8
63
x 82 1/2
61 7/8
x 81 3/4
64 1/2 x 83
67 1/2 x 84 1/2
5-4 x 6-8
67
x 82 1/2
65 7/8
x 81 3/4
68 1/2 x 83
71 1/2 x 84 1/2
6-0 x 6-8
75
x 82 1/2
73 7/8
x 81 3/4
76 1/2 x 83
79 1/2 x 84 1/2
For 8'-0" Height Units – add 16" to all height dimensions shown.
OUTSWING DOOR SYSTEM - STANDARD ALUMINUM SILL OR PUBLIC ACCESS SILL
– Oak & Mahogany Sill - ADD 3/4" to Height of all dimensions – Public Access Aluminum Sill - Use Table AS IS
Size
Rough Opening
Unit Dimension
No Casing
Unit Dimension
w/ Brickmould
Unit Dimension
w/ 1-1/16" x3-1/2"
Flat Casing
2-6 x 6-8
32 1/2
x 81 1/2
31 3/8
x 80 7/8
34 1/2 x 82 3/8
37 1/2 x 83 7/8
2-8 x 6-8
34 1/2
x 81 1/2
33 3/8
x 80 7/8
36 1/2 x 82 3/8
39 1/2 x 83 7/8
3-0 x 6-8
38 1/2
x 81 1/2
37 3/8
x 80 7/8
40 1/2 x 82 3/8
43 1/2 x 83 7/8
5-0 x 6-8
63
x 81 1/2
61 7/8
x 80 7/8
65
x 82 3/8
68
x 83 7/8
5-4 x 6-8
67
x 81 1/2
65 7/8
x 80 7/8
69
x 82 3/8
72
x 83 7/8
6-0 x 6-8
75
x 81 1/2
73 7/8
x 80 7/8
77
x 82 3/8
80
x 83 7/8
For 8'-0" Height Units – add 16" to all height dimensions shown.
DOOR & SIDELIGHT UNIT _ INSWING DOOR SYSTEM - STANDARD ALUMINUM SILL
Mull Post or Jamb to Jamb - Same Width Dimensions
– Oak & Mahogany Sill - ADD 1/2" to Height of all dimensions – Public Access Aluminum Sill - Deduct 1" from Height of all dimensions
Size
Rough Opening
Unit Dimension
No Casing
Unit Dimension
w/ Brickmould
Unit Dimension
w/ 1-1/16"x3-1/2"
Flat Casing
3-0 x 6-8
w/ (1) 10"
Sdlt
50
x 82 1/2
48 7/8
x 81 3/4
51 1/2
x 83
54 1/2
x 84 1/2
3-0 x 6-8
w/ (1) 12" Sdlt
52
x 82 1/2
50 7/8
x 81 3/4
53 1/2
x 83
56 1/2
x 84 1/2
3-0 x 6-8
w/ (1) 14" Sdlt
54
x 82 1/2
52 7/8
x 81 3/4
55 1/2
x 83
58 1/2
x 84 1/2
3-0 x 6-8
w/ (2) 10"
Sdlts
61 1/2
x 82 1/2
60 3/8
x 81 3/4
63 1/2
x 83
66 1/2
x 84 1/2
3-0 x 6-8
w/ (2) 12" Sdlts
65 1/2
x 82 1/2
64 3/8
x 81 3/4
67
x 83
70
x 84 1/2
3-0 x 6-8
w/ (2) 14" Sdlts
69 1/2
x 82 1/2
68 3/8
x 81 3/4
71
x 83
74
x 84 1/2
For Transom Unit Height add the Transom frame height to the appropriate dimension to obtain new height.
