Design-Pro Fiberglass Doors - Fir (DF)
Continued
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
1/2 View 1-Panel Plank
DF-684-1PL
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A
5"
6-1/8" 8-1/2"
DF7-684-1PL
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-1/2" 6-1/8" 11"
DF8-684-1PL
2'10", 3'0"
8'0" 23-1/8"
5-5/16", 6-5/16"
N/A 4-15/16" 7-3/16" 8-1/2"
Full View
DF-686
2'6", 2'8", 2'10", 3'0"
6'8" N/A 3-15/16", 3-15/16", 4-15/16", 5-15/16" N/A
5"
N/A 8-1/8"
DF7-686
2'6", 2'8", 2'10", 3'0"
7'0" N/A 3-15/16", 3-15/16", 4-15/16", 5-15/16" N/A 6-1/2" N/A 10-5/8"
DF8-686
2'8", 2'10", 3'0"
8'0" N/A
3-13/16", 4-13/16", 5-13/16"
N/A 4-7/8" N/A
8"
Design-Pro Fiberglass Sidelights - Fir (DF)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Sidelight Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
Full View
DF-690
1'0", 1'2"
6'8''
N/A
1-1/2", 2-1/2"
N/A
5"
N/A 8-1/8"
DF7-690
1'0'', 1'2''
7'0" N/A
1-1/2", 2-1/2"
N/A 6-1/2" N/A 10-5/8"
DF8-690
1'0'', 1'2''
8'0''
N/A
7/8", 1-7/8"
N/A 4-7/8" N/A
8"
1/2 View
DM-692
1'0'', 1'2''
6'8''
9-1/8"
1", 2"
N/A
5"
6-1/8" 8-1/2"
DM7-692
1'0'', 1'2''
7'0" 9-1/8"
1", 2"
N/A 6-1/2" 6-1/8" 11"
DM8-692
1'0", 1'2"
8'0" 9-1/8"
1", 2"
N/A 4-15/16" 6-3/16" 8-1/2"
Craftsman
DFC-820
1'0", 1'2"
6'8" 8-1/4"
1-13/16", 2-13/16"
N/A 5-3/8"
6" 8-9/16"
DFC7-820
1'0", 1'2"
7'0" 8-1/4"
1-13/16", 2-13/16"
N/A 6-7/8"
6" 11-1/16"
Craftsman Direct Glaze
DFC-820DG
1'0", 1'2"
6'8" 8-1/4"
1-13/16", 2-13/16"
N/A 5-3/8"
6" 8-9/16"
DFC7-820DG
1'0", 1'2"
7'0" 8-1/4"
1-13/16", 2-13/16"
N/A 6-7/8"
6" 11-1/16"
DFC8-820DG
1'0", 1'2"
8'0" 8-1/4"
1-13/16", 2-13/16"
N/A 5-3/8"
6" 8-9/16"
Beadboard Direct Glaze
DFB-820DG
1'0", 1'2"
6'8" 8-5/8"
1-5/8", 2-5/8"
N/A 5-3/8" 5-5/8" 8-9/16"
DFB7-820DG
1'0", 1'2"
7'0" 8-5/8"
1-5/8", 2-5/8"
N/A 6-7/8" 5-5/8" 11-1/16"
DFB8-820DG
1'0", 1'2"
8'0" 8-5/8"
1-5/8", 2-5/8"
N/A 5-3/8" 5-5/8" 8-9/16"
Craftsman/Beadboard Full View
DFC/DFB-819
1'0", 1'2"
6'8" N/A
1-15/16", 2-15/16"
N/A 5-1/2" N/A 8-1/2"
DFC7/DFB7-819
1'0", 1'2"
7'0" N/A
1-15/16", 2-15/16"
N/A 6-7/8" N/A 11-1/8"
Smooth-Pro Fiberglass Doors (SP)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
2-Panel Euro
SP-27
2'8", 2'10", 3'0"
6'8" 23-1/2"
4-1/8", 5-1/8", 6-1/8"
N/A 5-1/8" 5-7/8" 8-5/16"
2-Panel Square Top
SP-21
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-1/2" 8-1/2"
SP7-21
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-7/8" 6-1/2" 11"
SP8-21
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-5/8" 8-1/2"
2-Panel Arch Top
SP-20
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-1/2" 8-1/2"
SP7-20
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-7/8" 6-1/2" 11"
SP8-20
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-5/8" 8-1/2"
2-Panel Plank Arch Top
SP-24
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-1/2" 8-1/2"
SP7-24
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-7/8" 6-1/2" 11"
SP8-24
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 7-5/8" 8-1/2"
2-Panel 3/4 Arch Top
SP8-26
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/2" 8-5/8"
3-Panel 3/4 Top
SP-30
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/8" 8-1/2"
3/4 Oval
SP-949
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/8" 8-1/2"
Craftsman
SPC-866
2'8", 2'10", 3'0"
6'8" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
SPC7-866
2'8", 2'10", 3'0"
7'0" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 6-7/8"
6" 11-1/16"
Sunburst/Camber Top
SP-659/648
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-7/8" 6-1/2" 8-1/2"
4-Panel
SP-40
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
6-1/2" 5-3/8" 6-1/2" 8-1/2"
6-Panel
SP-60
2'6"
6'8" 8-5/16"
4-7/16"
4-7/8"
5"
6-1/8" 8-1/2"
SP-60
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8"
5"
6-1/8" 8-1/2"
SP7-60
2'8", 2'10", 3'0"
7'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 6-1/2" 6-1/8" 11"
SP8-60
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-15/16" 6-3/16" 8-1/2"
8-Panel Center Arch
SP-80
2'10", 3'0"
6'8" 6", 9"
4-5/16", 5-5/16"
1-1/2" / 2" 5-3/8" N/A 8-1/2"
8-Panel Center Arch Glass
SP-632
2'10", 3'0"
6'8" 6", 9"
4-5/16", 5-5/16"
1-1/2" / 2" 5-3/8" N/A 8-1/2"
DOOR & SIDELIGHT
SPECIFICATIONS
FIBERGLASS DOOR & SIDELIGHT SPECI FICATIONS
