Architectural Fiberglass Doors -
Rustic Cherry (AC-RP), Traditional Cherry (AC-TP), Mahogany (AM), Oak (AO), Fir (AFC), Knotty Alder (AK)
Door Series
Width Height
Panel
Width
Outer
Stiles
Center
Mullion
Top
Rail
Lock
Rail
Bottom
Rail
Rustic Cherry
2-Panel Arch Top AC-25-RP
3'0" 6'8" 23-3/16" 6-5/16"
N/A
4-15/16"
3-13/16"
7-3/4"
2-Panel Arch Top AC7-25-RP
3'0" 7'0" 23-3/16" 6-5/16"
N/A
7-7/16"
3-13/16"
10-1/8"
2-Panel Arch Top AC8-25-RP
3'0" 8'0" 23-3/16" 6-5/16"
N/A
4-11/16"
3-3/4"
8"
2-Panel Plank Arch Top AC-26-RP
3'0" 6'8" 23-3/16" 6-5/16"
N/A
4-15/16"
3-13/16"
7-3/4"
2-Panel Plank Arch Top AC8-26-RP
3'0" 8'0" 23-3/16" 6-5/16"
N/A
4-11/16"
3-3/4"
8"
Traditional Cherry
2-Panel AC-28-TP
3'0" 6'8" 23-3/16" 6-5/16"
N/A
6-1/8"
3-13/16"
7-3/4"
2-Panel Plank AC-29-TP
3'0" 6'8" 23-3/16" 6-5/16"
N/A
6-1/8"
3-13/16"
7-3/4"
3-Panel AC-30-TP
3'0" 6'8" 23-3/16" 6-5/16"
N/A
4-7/8"
3-13/16"
7-13/16"
6-Panel AC-60-TP
3'0" 6'8" 9-1/8" 6-5/16" 4-7/8"
5-7/8"
6-3/16"
8"
8-Panel Center Arch AC-80-TP
3'0" 6'8" 25-1/4" 5-1/4"
N/A
5-3/8"
N/A
7-3/4"
Mahogany
3-Panel AM-30
3'0" 6'8" 23-3/16" 6-5/16"
N/A
4-7/8"
3-13/16"
7-13/16"
6-Panel AM-60
3'0" 6'8" 9-1/8" 6-5/16" 4-7/8"
5-7/8"
6-3/16"
8"
Oak
2-Panel AO-28
3'0" 6'8" 23-3/16" 6-5/16"
N/A
6-1/8"
3-13/16"
7-3/4"
6-Panel AO-60
3'0" 6'8" 9-1/8" 6-5/16" 4-7/8"
5-7/8"
6-3/16"
8"
Fir Craftsman
3-Panel AFC-30
3'0" 6'8" 26-1/8" 4-13/16"
4"
4-11/16"
4-1/4"
8"
Knotty Alder
2-Panel Arch Top AK-20
3'0" 6'8" 23-3/16" 6-5/16"
N/A
5-15/16"
6-1/16"
8"
2-Panel Arch Top AK8-20
3'0" 8'0" 23-3/16" 6-5/16"
N/A
6-9/16"
7-1/8"
9-3/16"
Architectural Fiberglass Sidelights -
Rustic Cherry (AC-RP), Traditional Cherry (AC-TP), Mahogany (AM), Oak (AO), Fir (AFC), Knotty Alder (AK)
Sidelight Series
Width Height Panel
Width
Outer
Stiles
Center
Mullion
Top
Rail
Lock
Rail
Bottom Rail
Rustic Cherry
Full View AC-690
1'0", 1'2" 6'8" N/A 7/8", 1-7/8" N/A
5-13/16"
N/A
7-1/8"
Full View AC7-690
1'0", 1'2" 7'0" N/A 7/8", 1-7/8" N/A
7-15/16"
N/A
9-7/8"
3/4 View AC-422-RP
1'0", 1'2" 6'8" 9-1/8" 7/8", 1-7/8" N/A
4-7/16"
3-5/16"
7-3/4"
3/4 View AC7-422-RP
1'0", 1'2" 7'0" 9-1/8" 7/8", 1-7/8" N/A
6-15/16"
3-5/16"
10-1/8"
3/4 View AC8-422-RP
1'0", 1'2" 8'0" 9-1/8" 7/8", 1-7/8" N/A
4-3/16"
3-3/8"
8"
Traditional Cherry, Mahogany, Oak
Full View AC-690-TP, AM-690, AO-690* 1'0", 1'2" 6'8" N/A 7/8", 1-7/8" N/A 5-5/16", 5-7/16", 5-11/16"
N/A
7-11/16", 7-1/2", 7-5/16"
3/4 View AC-422-TP, AM-422, AO-422* 1'0", 1'2" 6'8" 9-1/8" 7/8", 1-7/8" N/A 4-7/16", 5-1/16", 5-11/16" 3-3/8", 2-11/16", 2-1/16"
7-3/4"
1/2 View AC-692-TP, AM-692, AO-692 1'0", 1'2" 6'8" 9-1/8" 7/8", 1-7/8" N/A
5-7/16"
5-3/4"
8"
Fir Craftsman
Full View AFC-819
1'0", 1'2" 6'8" N/A 3/4", 1-3/4" N/A
4-11/16"
N/A
8"
Knotty Alder
Full View AK-690
1'0", 1'2" 6'8" N/A 7/8", 1-7/8" N/A
5-7/16"
N/A
7-1/2"
Design-Pro Fiberglass Doors - Mahogany (DM)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
2-Panel Euro
DM-27
2'8", 2'10", 3'0"
6'8" 23-1/2"
4-1/8", 5-1/8", 6-1/8"
N/A 5-1/8" 5-7/8" 8-5/16"
2-Panel Arch Top
DM-20
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-1/2" 8-1/2"
DM7-20
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-7/8" 6-1/2" 11"
DM8-20
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-5/8" 8-1/2"
2-Panel Plank Arch Top
DM-24
2'10", 3'0"
6'8" 25-1/8"
4-5/16", 5-5/16"
N/A
5"
6"
8-1/2"
DM8-24
2'10", 3'0"
8'0" 25-1/8"
4-5/16", 5-5/16"
N/A
5"
6"
8-1/2"
2-Panel 3/4 Arch Top
DM8-26
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/2" 8-5/8"
3-Panel 3/4 Top
DM-30
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/8" 8-1/2"
3/4 Oval
DM-949
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/8" 8-1/2"
3-Panel Scroll
DM-31
2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16"
N/A 4-1/4" 3-13/16" 8-1/2"
3-Panel Scroll with 3/4 Oval
DM-949-2S
2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16"
N/A 4-1/4" 3-13/16" 8-1/2"
Craftsman 2-panel
DMC-866
2'8", 2'10", 3'0"
6'8" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
DMC7-866
2'8", 2'10", 3'0"
7'0" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 6-7/8"
6" 11-1/16"
Craftsman Direct Glaze 2-panel
DMC-866DG
2'8", 2'10", 3'0"
6'8" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
DMC7-866DG
2'8", 2'10", 3'0"
7'0" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 6-7/8"
6" 11-1/16"
DMC8-866DG
2'10", 3'0"
8'0" 9-1/4"
5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
6-Panel
DM-60
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 5-3/8" 6-1/2" 8-1/2"
DM7-60
2'8", 2'10", 3'0"
7'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 6-7/8" 6-1/2" 11"
DM8-60
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 5-3/8" 6-5/8" 8-1/2"
JELD-WEN, inc. reserves the right to change specifications without notice.
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
*Rail dimensions vary based on door selection.
