Design-Pro Fiberglass Doors - Oak (DO)
Continued
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
1/2 View 2-Panel
DO-684
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8"
5"
6-1/8" 8-1/2"
DO8-684
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-15/16" 6-3/16" 8-1/2"
3/4 View 2-Panel
DO-607
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-15/16" 3-11/16" 8-1/2"
3/4 View 1-Panel
DO-607-1P
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 3-11/16" 8-1/2"
DO8-6071P
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 4-1/16" 8-5/8"
Full Oval
DO-919
2'8", 2'10", 3'0"
6'8" N/A
4-13/16", 5-13/16", 6-13/16"
N/A 8-7/8" N/A 11-7/8"
DO7-919
2'8", 2'10", 3'0"
7'0" N/A
4-13/16", 5-13/16", 6-13/16"
N/A 10-3/8" N/A 14-3/8"
DO8-919
2'8", 2'10", 3'0"
8'0" N/A
4-13/16", 5-13/16", 6-13/16"
N/A 16-7/8 N/A 19-7/8"
Full View
DO-686
2'8", 2'10", 3'0"
6'8" N/A
3-15/16", 4-15/16", 5-15/16"
N/A
5"
N/A 8-1/8"
DO7-686
2'8", 2'10", 3'0"
7'0" N/A
3-15/16", 4-15/16", 5-15/16"
N/A 6-1/2" N/A 10-5/8"
DO8-686
2'8", 2'10", 3'0"
8'0" N/A
3-13/16", 4-13/16", 5-13/16"
N/A 4-7/8" N/A
8"
Design-Pro Fiberglass Sidelights - Oak (DO)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Sidelight Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
Full View
DO-690
10", 1'0'', 1'2''
6'8''
N/A
1", 1-1/2", 2-1/2"
N/A
5"
N/A 8-1/8"
DO7-690
10", 1'0'', 1'2''
6'8''
N/A
1", 1-1/2", 2-1/2"
N/A 6-1/2" N/A 10-5/8"
DO8-690
1'0'', 1'2''
8'0''
N/A
7/8", 1-7/8"
N/A 4-7/8" N/A
8"
3/4 View
DO-422
1'0'', 1'2''
6'8''
9-1/2"
1", 2"
N/A 4-15/16" 3-11/16" 8-1/2"
DO8-422
1'0'', 1'2''
8'0" 9-1/8"
1-1/2", 2-1/2"
N/A 4-13/16" 4-1/16" 8-5/8"
1/2 View
DO-692
1'0'', 1'2''
6'8''
9-1/8"
1", 2"
N/A
5"
6-1/8" 8-1/2"
DO8-692
1'0", 1'2"
8'0" 9-1/8"
1", 2"
N/A 4-15/16" 6-3/16" 8-1/2"
Craftsman Full View Direct Glaze
DOC-819DG
1'0", 1'2"
6'8" N/A
2-7/8", 3-7/8"
N/A 5-3/8" N/A 8-3/8"
DOC8-819DG
1'0", 1'2"
8'0" N/A
2-7/8", 3-7/8"
N/A 5-3/8" N/A 8-3/8"
Design-Pro Fiberglass Doors - Fir (DF)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
2-Panel Square Top
DF-21
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-1/2" 8-1/2"
DF7-21
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-7/8" 6-1/2" 11"
DF8-21
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-5/8" 8-1/2"
2-Panel Arch Top
DF-20
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-1/2" 8-1/2"
DF7-20
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-7/8" 6-1/2" 11"
DF8-20
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-5/8" 8-1/2"
2-Panel Plank Arch Top
DF-24
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 6-1/2" 8-1/2"
DF7-24
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-7/8" 6-1/2" 11"
DF8-24
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 7-5/8" 8-1/2"
Craftsman
DFC-866
2'8", 2'10", 3'0"
6'8" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 5-3/8" NA 8-9/16"
DFC7-866
2'8", 2'10", 3'0"
7'0" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 6-7/8" NA 11-1/16"
Craftsman Direct Glaze
DFC-866DG
2'8", 2'10", 3'0"
6'8" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
DFC7-866DG
2'8", 2'10", 3'0"
7'0" 9-1/4"
4-1/4", 5-1/4", 6-1/4"
4-3/4" 6-7/8"
6" 11-1/16"
DFC8-866DG
2'10", 3'0"
8'0" 9-1/4"
5-1/4", 6-1/4"
4-3/4" 5-3/8"
6" 8-9/16"
Beadboard Direct Glaze
DFB-866DG
2'8", 2'10", 3'0"
6'8" 23-5/8"
4-1/16", 5-1/16", 6-1/16"
N/A 5-3/8" 5-5/8" 8-9/16"
DFB7-866DG
2'8", 2'10", 3'0"
7'0" 23-5/8"
4-1/16", 5-1/16", 6-1/16"
N/A 6-7/8" 5-5/8" 11-1/16"
DFB8-866DG
2'10", 3'0"
8'0" 23-5/8"
4-1/16", 5-1/16", 6-1/16"
N/A 5-3/8" 5-5/8" 8-9/16"
6-Panel
DF-60
2'6"
6'8" 8-5/16"
4-7/16"
4-5/16" 5-3/8" 6-1/2" 8-1/2"
DF-60
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 5-3/8" 6-1/2" 8-1/2"
DF7-60
2'8", 2'10", 3'0"
7'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 6-7/8" 6-1/2" 11"
DF8-60
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 5-3/8" 8-9/16" 8-1/2"
1/2 View 2-Panel
DF-684
2'6"
6'8" 8-5/16"
4-7/16"
4-7/8"
5"
6-1/8" 8-1/2"
DF-684
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8"
5"
6-1/8" 8-1/2"
DF7-684
2'8", 2'10", 3'0"
7'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 6-1/2" 6-1/8" 11"
DF8-684
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-15/16" 6-3/16" 8-1/2"
1/2 View 1-Panel
DF-684-1P
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A
5"
6-1/8" 8-1/2"
DF7-684-1P
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 6-1/2" 6-1/8" 11"
DF8-684-1P
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 6-3/16" 8-1/2"
JELD-WEN, inc. reserves the right to change specifications without notice.
DOOR & SIDELIGHT
SPECIFICATIONS
FIBERGLASS DOOR & SIDELIGHT SPECI FICATIONS
