JELD-WEN.COMDesign-Pro Fiberglass Doors - Mahogany (DM)
Continued
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
8-Panel Center Arch
DM-80
2'10", 3'0"
6'8" 6", 9"
4-5/16", 5-5/16"
1-1/2" / 2" 5-3/8" N/A 8-1/2"
8-Panel Center Arch Glass
DM-632
2'10", 3'0"
6'8" 6", 9"
4-5/16", 5-5/16"
1-1/2" / 2" 5-3/8" N/A 8-1/2"
1/2 View 2-Panel
DM-684
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8"
5"
6-1/8" 8-1/2"
DM7-684
2'8", 2'10", 3'0"
7'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 6-1/2" 6-1/8" 11"
DM8-684
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-15/16" 6-3/16" 8-1/2"
1/2 View 1-Panel
DM-684-1P
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A
5"
6-1/8" 8-1/2"
DM7-684-1P
2'8", 2'10", 3'0"
7'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
NA 6-1/2" 6-1/8" 11"
DM8-684-1P
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 6-3/16" 8-1/2"
3/4 View 2-Panel
DM-607
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-15/16" 3-11/16" 8-1/2"
3/4 View 1-Panel
DM-607-1P
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 3-11/16" 8-1/2"
DM8-607-1P
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 4-15/16" 4-1/16" 8-5/8"
Full View
DM-686
2'8", 2'10", 3'0"
6'8" N/A
3-15/16", 4-15/16", 5-15/16"
N/A
5"
N/A 8-1/8"
DM7-686
2'8", 2'10", 3'0"
7'0" N/A
3-15/16", 4-15/16", 5-15/16"
N/A 6-1/2" N/A 10-5/8"
DM8-686
2'8", 2'10", 3'0"
8'0" N/A
3-13/16", 4-13/16", 5-13/16"
N/A 4-7/8" N/A
8"
Design-Pro Fiberglass Sidelights - Mahogany (DM)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Sidelight Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
Full View
DM-690
1'0'', 1'2''
6'8''
N/A
1-1/2", 2-1/2"
N/A
5"
N/A 8-1/8"
DM7-690
1'0'', 1'2''
7'0" N/A
1-1/2", 2-1/2"
N/A 6-1/2" N/A 10-5/8"
DM8-690
1'0'', 1'2''
8'0''
N/A
7/8", 1-7/8"
N/A 4-7/8" N/A
8"
3/4 View
DM-422
1'0'', 1'2''
6'8''
9-1/2"
1", 2"
N/A 4-15/16" 3-11/16" 8-1/2"
DM8-422
1'0'', 1'2''
8'0" 9-1/8"
1-1/2", 2-1/2"
N/A 4-15/16" 4-1/16" 8-5/8"
1/2 View
DM-692
1'0'', 1'2''
6'8''
9-1/8"
1", 2"
N/A
5"
6-1/8" 8-1/2"
DM7-692
1'0'', 1'2''
7'0" 9-1/8"
1", 2"
N/A 6-1/2" 6-1/8" 11"
DM8-692
1'0", 1'2"
8'0" 9-1/8"
1", 2"
N/A 4-15/16" 6-3/16" 8-1/2"
Craftsman
DMC-820
1'0", 1'2"
6'8" 8-1/4"
1-13/16", 2-13/16"
N/A 5-3/8" NA 8-9/16"
DMC7-820
1'0", 1'2"
7'0" 8-1/4"
1-13/16", 2-13/16"
N/A 6-7/8" NA 11-1/16"
Craftsman Direct Glaze 1-Panel
DMC-820DG
1'0", 1'2"
6'8" 8-1/4"
1-13/16", 2-13/16"
N/A 5-3/8"
6" 8-9/16"
DMC7-820DG
1'0", 1'2"
7'0" 8-1/4"
1-13/16", 2-13/16"
N/A 6-7/8"
6" 11-1/16"
DMC8-820DG
1'0", 1'2"
8'0" 8-1/4"
1-13/16", 2-13/16"
N/A 5-3/8"
6" 8-9/16"
Craftsman Full View
DMC-819
1'0", 1'2"
6'8" N/A
2-7/8", 3-7/8"
N/A 5-3/8" N/A 8-3/8"
DMC7-819
1'0", 1'2"
8'0" N/A
2-7/8", 3-7/8"
N/A 5-3/8" N/A 8-3/8"
Design-Pro Fiberglass Doors - Oak (DO)
6'8" = 79"; 7'0" = 83"; 8'0" = 95"
Door Series
Width
Height Panel
Width
Outer Stiles
Center
Mullion Top Rail Lock
Rail
Bottom
Rail
2-Panel Euro
DO-27
2'8", 2'10", 3'0"
6'8" 23-1/2"
4-1/8", 5-1/8", 6-1/8"
N/A 5-1/8" 5-7/8" 8-5/16"
2-Panel 3/4 Arch Top
D08-26
2'8", 2'10", 3'0"
8'0" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/2" 8-5/8"
3-Panel 3/4 Top
DO-30
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/8" 8-1/2"
3/4 Oval
DO-949
2'8", 2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16", 6-5/16"
N/A 5-3/8" 4-1/8" 8-1/2"
3/4 Oval Scroll
DO-31
2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16"
N/A 4-1/4" 3-13/16" 8-1/2"
3/4 Oval Scroll
DO-949-2S
2'10", 3'0"
6'8" 23-1/8"
4-5/16", 5-5/16"
N/A 4-1/4" 3-13/16" 8-1/2"
Craftsman Direct Glaze 3- Panel
DOC-866DG
2'10", 3'0"
6'8" 6-3/8"
4-1/2", 5-1/2"
2-13/16" 5-3/8" 5-1/2" 8-1/2"
DOC8-866DG
2'10", 3'0"
8'0" 6-3/8"
4-1/2", 5-1/2"
2-13/16" 5-3/8" 5-1/2" 8-1/2"
Sunburst/Camber Top
DO-659/648
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 4-7/8" 6-1/2" 8-1/2"
4-Panel
DO-40
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
6-1/2" 5-3/8" 6-1/2" 8-1/2"
Twin 1/2 View
DO-692
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8"
5"
6-1/8" 8-1/2"
6-Panel
DO-60
2'8", 2'10", 3'0"
6'8" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 5-3/8" 6-1/2" 8-1/2"
DO8-60
2'8", 2'10", 3'0"
8'0" 9-1/8"
4-5/16", 5-5/16", 6-5/16"
4-7/8" 5-3/8" 8-9/16" 8-1/2"
JELD-WEN, inc. reserves the right to change specifications without notice.
