Haas Architectural Millwork - Ph. (717) 840-4227 - Fax (717) 840-4228
Email:
B
A
L
U
S
T
R
A
D
E
7-1/4" Balustrade System Continued
Height Bottom Width Top Width
7" 5-3/4" 5-1/2"
RADIUS RAILS AVAILABLE - Contact us for a quote.
Height Bottom Width Top Width
5-3/4" 7-1/4" 5-1/2"
HTR 214 - 8', 10' , 12' Top Rail HBR 215 - 8' , 10', 12' Bottom Rail
HBAL 119
Height Width Part No.
HBAL 119-16 4-1/2" 16"
HBAL 119-20 4-1/2" 20"
HBAL 119-24 4-1/2" 24"
Spacing on Center - 6-1/4 "
HBAL 120
Height Width Part No.
HBAL 120-28 5-1/4 " 28"
Spacing on Center - 6-7/8"
HBAL 118
Height Width Part No.
HBAL 118-19 5-1/4" 19"
HBAL 118-22 5-1/4" 22"
HSBAL 118-24 5-1/4"
5-1/4" HSBAL 118-27
HSBAL 118-35 5-1/4"
Spacing on Center - 6-7/8"
Installation instructions
Page 28-34.
HTR 214 / HBR 215
HBAL 107
Height Width Part No.
HBAL 107-28 4" 28 "
Spacing on Center - 6-3/8 "
Height Bottom Width Top Width
7-1/4" 5-1/2" 5-1/2"
Part No.
HTRG 206-8'
HTRG 206-10'
HTRG 206-12'
Description
Gooseneck Rail
Gooseneck Rail
Gooseneck Rail
HTRG 206 - Goose Neck Rail
* 4-1/2 " Gooseneck drop.
HSBAL 107-36 4" 36 "
*(HSBAL) are balusters with extended
blocks. The can be used for stair
applications or as a taller baluster.
22" Ext 24"
22 " Ext 35"
22 " Ext 27"
