Haas Architectural Millwork - Ph. (717) 840-4227 - Fax (717) 840-4228
Email:
4-1/2" Balustrade System Continued
PLAIN NEWEL POSTS
Part No. Width Height
HNP 300-6
HNP 300-8
HNP 300-8-18
5-1/2 "
8"
8"
48"
48"
18-1/2"
STAINLESS STEEL
KITS AVAILABLE
FOR COASTAL
APPLICATIONS
Part No.
HNPK 300-6
HNPK 300-8
NEWEL KITS
RAISED PANEL NEWEL POST
In-Line
HPNP 301-8 HCNP 302-8 HSNP 303-8
Corner End
Width 8" X Height 48"
Specify Concrete or Wood
C = Concrete
W = Wood
Ex. HNPK 300-8-C
Part No.
In-Line
HPNP 307-8 HCNP 308-8 HSNP 309-8
Corner End
Width 8" X Height 48"
Part No.
RECESSED FLAT PANEL NEWEL POST
NEWEL CAPS
Part No. Width Height
TRIM COLLARS
HNC 300-6 6-1/4" 1-1/2"
HNC 300-8 8-1/2" 1-1/2"
HFNC 301-6 6-3/8" 2-1/2"
HFNC 301-8 8-3/4" 2-3/4"
HPNC 302-6 6-1/2" 2 "
HPNC 302-8 8-3/4" 2-1/4"
HTC 300-6
Part No.
HTC 300-8
5-1/2"
Width
2-1/8"
Height
10-1/2 " 2-1/8"
HPNC 302-1-6 6-1/2" 1-1/2"
HPNC 302-1-8 8-3/4" 1-3/4"
Part No. Base Dia Height
HBALL 600-6
HBALL 600-7
HBALL 600-5
8"
6-1/2"
6"
5"
9-1/2" 7"
BALL TOPS
5-1/2"
8"
10-3/4"
10-3/4"
HTC 302-6
HTC 302-8
HNPB can be modified in height.
RAIL KITS / STAIR RAIL KITS
Part No. HRK 202 / HRKS 202
**Customer must specify rise and run of stairs.
1 KIT PER TOP & BOTTOM RAIL SECTION
Part No. HRK 760 / HRKS 760
*Contact us for CAD drawings.
Installation Instructions
Pages 28-34.
