5-1/2" Balustrade System Continued
PLAIN NEWEL POSTS
Part No. Width Height
HNP 300-8
HNP 300-9
HNP 300-8-18
8"
9"
8"
48"
48"
18-1/2"
RAISED PANEL NEWEL POST
5-SIDED PLAIN NEWEL POSTS
Hght
8" - 5 sided 48"
Measurements
HAPNP 310-8
RECESSED FLAT PANEL NEWEL POSTS
In-Line
HPNP 307-8 HCNP 308-8 HSNP 309-8
Corner End
Width 8" x 48"
In-Line
HPNP 301-8 HCNP 302-8 HSNP 303-8
Corner End
Width 8" x 48"
HPNP 301-9 HCNP 302-9 HSNP 303-9
Width 9" x 48"
Part No.
Part No.
HBAL 194
Height Width Part No.
HBAL 194-31 3-1/2" 31"
Spacing on Center - 5-3/8"
2 HBAL 186
Height Width Part No.
HBAL 186-22 3-1/4" 22-5/8"
Spacing on Center - 5-5/8"
Part No.
HSB 900
RAIL SUPPORT BLOCK
Height Width
4 " 3-1/2"
Fits all rail sizes.
Length
5-1/2"
Installation Instructions
Pages 28-34.
*(HSBAL) are balusters with extended
blocks. The can be used for stair
applications or as a taller baluster.
Part No.
