5-1/2" Balustrade System
Spacing on Center - 6"
HBAL 109
Height Width Part No.
HBAL 109-19 3-3/4" 19"
HSBAL 109-22 3-3/4"
HSBAL 109-24 3-3/4" 19" Ext 24-1/2"
3-3/4 " 26" HBAL 109-26
HSBAL 109-30
HBAL 109-32
3-3/4 "
3-3/4 " 32"
Spacing on Center - 6"
HBAL 113
Height Width Part No.
HBAL 113-24 3-5/8" 24 "
HSBAL 113-26 3-5/8" 26 "
HSBAL 113-30 3-5/8" 30 "
HTR 204 / HBR 205
RADIUS RAILS AVAILABLE - CONTACT US
Height Bottom Width Top Width
5-1/2" 4" 4"
Height Bottom Width Top Width
4 " 5-1/2" 4 "
HBR 205 - 8' , 10', 12' Bottom Rail HTR 204 - 8', 10', 12' Top Rail
HTR 218
RADIUS RAILS AVAILABLE - CONTACT US FOR A QUOTE
Height Bottom Width Top Width
5-1/2" 4" 4 "
HTR 218 - 8', 10', 12' Top Rail
HBAL 144
Height Width Part No.
HBAL 144-23 3-3/4" 23"
Spacing on Center - 6"
HBAL 145
Height Width Part No.
Spacing on Center - 5-7/8 "
RAIL KITS / STAIR RAIL KITS
Part No. HRK 204 / HRKS 204
**Customer must specify rise and run of stairs.
1 KIT PER TOP & BOTTOM RAIL SECTION
See page 28-34.
Part No. HRK 218 / HRKS 218
19" Ext 22"
19" Ext 30"
HBAL 145-28 3-7/8" 28"
