haasmillwork@haasmillwork.comBALUSTRADE SYSTEM Installation Instructions
Newel Post Installation Kit
(Order 1 kit per Newel Post)
Wood Kit
1. One floor flange
2. Four 3/8
"
x 2
"
lag bolts
3. One 1/2
"
x 48
"
threaded rod
4. One “C
"
channel
5. One 1/2
"
flat washer
6. One 1/2
"
lock washer
7. One 1/2
"
Nut
Concrete Kit
1. One floor flange
2. Four 3/8
"
x 2 1/4
"
concrete wedge bolts
3. One 1/2
"
x 48
"
threaded rod
4. One “C
"
channel
5. O ne 1/2
"
flat washer
6. One 1/2
"
lock washer
7. One 1/2
"
nut
Kit Number*
Newel Posts
HNPK 300-4
Fits all 4
"
newel posts
HNPK 300-6 Fits all 5 1/2
"
newel posts
HNPK 300-8 Fits all 8
"
newel posts
HNPK 300-9 Fits all 9
"
newel posts
HNPK 300-10 Fits all 10
"
newel posts
HNPK 300-12 Fits all 12
"
newel posts
*Note: Newel Kits are available for either
wood or concrete application. To
specify please add -W for wood or -C for
concrete to the end of the kit number.
Ex. (HNPK 300-4-W or HNPK 302-8-C)
MADE IN THE
USA
Railing Installation Kit
(Order 1 kit per Top & Bottom Rail Section.)
Railing Kit
1. Two pre-drilled aluminum angle
brackets. (Top Rail)
2. Two pre-drilled aluminum angle brackets
w/ 5/16
"
tapped hole. (Bottom Rail)
3. Eight #14 x 2
"
self tapping screws.
4. Four 1/4
"
x 2
"
Panhead bolts.
4. Two 5/16
"
x 1 1/2
"
hex head bolts.
Kit Number
Fits These Rails
HRK 180 HTR 180, HTR 232-HBR 233,
HTR 212-HBR 213
HRK 200
HTR 182-HBR 183
HTR 200-HBR 201,
HTR 202-HBR 203
HTR 210-HBR 211
HTR 760-HBR 761
HRK 204
HTR 204-HBR 205,
HTR 218, HTR 220
HRK 206
HTR 206-HBR 207,
HTR 214-HBR 215
HRK 208
HTR 208-HBR 209,
HTR 216
STAIR RAIL KITS
Simply add an
HRK-(S)
HRK
S
200
*Note: Must provide rise & run.
