90-MINUTE RATED FIRE DOOR SYSTEMS
Steel 6'6", 6'8", 7'0" and 8'0" Doors
Flush
Door
2'0" 2'6" 2'8" 2'10" 3'0"
6'6" 90CT-100
• •
•
6'8" 90CT-100 • • • • •
7'0" 90CT7-100 • • • • •
8'0" 90CT8-100 • • • • •
6-Panel - Beaded
Door
2'6" 2'8" 2'10" 3'0"
6'6" 90CT-60 • •
•
6'8" 90CT-60 • • • •
7'0" 90CT7-60
•
•
6-Panel - Ovolo
Door
2'6" 2'8" 2'10" 3'0"
6'8" 90CT-60 • • • •
8'0" 90CT8-60 • • • •
8-Panel - Beaded
Door
2'8" 2'10" 3'0"
6'8" 90CT-80 • • •
9-Panel - Beaded
Door
2'8" 2'10" 3'0"
6'8" 90CT-90 • • •
2-Panel Arch Top
Tiered
Door
2'8" 2'10" 3'0"
6'8" 90CT-20 • • •
4-Panel - Ovolo
Door
2'8" 2'10" 3'0"
6'8" 90CT-40 • • •
4-Panel Arch Top
Ovolo
Door
2'8" 2'10" 3'0"
6'8" 90CT-41 • • •
2-Panel Square Top
Tiered
Door
2'8" 2'10" 3'0"
6'8" 90CT-21 • • •
3-Panel - Beaded
Door
2'8" 2'10" 3'0"
6'8" 90CT-30 • • •
1-Panel Flat
Door
2'8" 2'10" 3'0"
6'8" 90CF-10 • • •
2-Panel Flat
Door
2'8" 2'10" 3'0"
6'8" 90CF-20 • • •
3-Panel Flat
Door
2'8" 2'10" 3'0"
6'8" 90CF-30 • • •
Diamond/6-Panel
Door
2'8" 2'10" 3'0"
6'8" 20CT-10D60 • • •
Diamond/Diamond
Door
2'8" 2'10" 3'0"
6'8" 20CT-10D • • •
New!
New!
FIRE RATED DOORS
FIRE RATED DOORS
Unmatched adjustability, ease of installation and reliability distinguish the Fire Frame kerf
steel door frame. Designed and manufactured for a full range of residential and commercial
installations in wood or steel stud construction, Fire Frame features a full 1" of adjustability
to accommodate most variations in wall construction. Extensive engineering and thorough
testing enable this frame to meet the most stringent code requirements including the proper
closing and latching specified for a full 90-minute fire rating.
STRUCTURAL PERFORMANCE AND IMPACT RATING
Design pressure ratings available for compliance with national, state and local wind load and/
or missile requirements. Product approval under the Miami-Dade BCCO NOA or Intertek-testing
Services/Warnock Hersey
®
programs.
DOOR SELECTION
Fire Frame is available in either right or left hand, both inswing and outswing, for use with any
entry door. Available in 6'8", 7'0" and 8'0" heights. Fits wall sizes from 4-1/2" thru 10-1/2"
based on 1" increments.
F R A M E
FIRE LABELS
90 Minute Fire Rating up to 3'-0" x 8'-0" Single.
