Installation Instructions
It’s time to put that signature finish to your project. Your column or post is ready to be installed
and we want to lend a hand. We have designed the installation instructions to ease the
process of putting your product in place. All the details are on one page. Follow step-by-step
instructions for easier installation. A set of specific installation instructions will be included
in the product box and as with most of our information, it is accessible online at our website,
www.columnpost.comor through your distributor.
Product Drawings
By now you have seen product that has spiked some interest. Which column, post, capital or
base would look best for your project? In order to help you make that decision, Column & Post
has provided a comprehensive set of product drawings that can be obtained through your
distributor or via our website at
www.columnpost.com .This is where you can review details to
assist in narrowing your choice.
Email us at:
info@columnpost.comInstallation Instructions
and
Product Drawings
Load-Bearing Specifications
Our product is tested using concentric loading. You will find load limits listed in our printed
literature in addition to the Column & Post Website,
www.columnpost.comand product
drawings. The load limits are specific to a product’s diameter or profile and predicated on
100% coverage at the top and bottom of a column or post.
Fire Rated Product
Column & Post has fire rated products available for purchase. Our fire rated
products have received Class A Certification through testing for flame spread
and smoke developed standards set forth in the ASTM E84 Test.
Technical
Product Data
Diameter
6”
8”
10”
12”
14”
16”
18”
20”
24”
Columns
8,000 lbs 10,000 lbs 14,000 lbs 18,000 lbs 20,000 lbs 20,000 lbs 20,000 lbs 20,000 lbs 20,000 lbs
Posts
8,000 lbs 10,000 lbs 12,000 lbs 14,000 lbs 14,000 lbs
n/a
n/a
n/a
n/a
Craftsman Posts
n/a
8,000 lbs
8,000 lbs
8,000 lbs
n/a
8,000 lbs
n/a
n/a
n/a
Herculite Posts
n/a
5,000 lbs
5,000 lbs
5,000 lbs
n/a
n/a
n/a
n/a
n/a
Porch Posts
3,000 lbs
25
