A = Unsplit or whole
round column
B = 1/4 Cut out for
outside corner
C =2/3 Cut out for pilaster D = Split in 1/2 (two halves)
A B C D
Q = 1/4 Cut out for
inside corner
W = Cut out for a wall wrap E = Unsplit or whole
square post
F = Split in 1/2 (two halves)
Q W E F
G = Cut out for an
inside corner
H = Cut out for an
outside corner
K = Cut out for a wall wrap L = Cut out for outside
flush wall wrap
G H K L
Getting you exactly what you need is a principal element of our business. Your satisfaction is a main concern
at Column & Post. We understand that dimensions vary by project. Sometimes the post height is a little
taller than a standard 8x8 or a column needs to be slightly short of 18 feet. Whatever the requirement, our
personnel can make the modifications that suit the needs of your endeavor.
Plan Types
Just like custom lengths can be
required to properly fit an opening,
it is sometimes necessary to make
vertical cuts. The scope of your project
may call for the use of half columns or
posts as pilasters or maybe you need
a quarter cut column for a room corner.
We have the ability to meet your
specifications. The graphic to the right
shows the many plan types available for
vertically splitting your column or post.
Installation Kits and Hardware
Custom Cuts and
Custom Products
Split columns can add an
element of sophistication to
even the smallest spaces.
Split Reassembly Kit
• 1 – 150ml Adhesive Cartridge with Adapter
• 1 – Roll of 3M/Scotch Bonding Tape
Simpson Strong-Tie Products
Column & Post recommends Simpson
Strong-Tie Products. Simpson Strong-Tie
features Hollow Column Uplift
Connections using 2 techniques.
1. Anchored Galvanized Steel Coil Strap, or...
2. Anchored Threaded Steel Rod.
/ 800.999.5099
Standard Column Installation
Bracket Kits
Kit includes brackets and screws to
install one column.
24
CUSTOM CUTS AND PRODUCTS / PLAN TYPES / INSTALLATION KITS
Round Column
Bracket
Square Column
Bracket
