103 / 196
103
Indicates Low-E Glass
SMOOTH-PRO FIBERGLASS
Full View 15-Light
(18-Light - 8'0")
Door
2'6" 2'8" 2'10" 3'0"
SP-686DG-CM15-LE • • • •
SP7-686DG-CM15-LE • • • •
SP-686DG-IM15-LE • • • •
SP7-686DG-IM15-LE • • • •
SP8-686DG-IM18-LE • • • •
686DG-IM15 available as 7/8" muntin
1/2 View 9-Light
Door
2'8" 2'10" 3'0"
SP-684DG-IM9-LE • • •
SP7-684DG-IM9-LE • • •
3/4 View 12-Light
(15-Light - 8'0")
Door
2'6" 2'8" 2'10" 3'0"
SP-607DG-IM12-LE • • • •
SP7-607DG-IM12-LE • • • •
SP8-607DG-IM15-LE • • • •
Full View 10-Light
(12-Light - 8'0")
Door
2'0" 2'4" 2'6" 2'8" 2'10" 3'0"
SP-686DG-IM10-LE • • • • • •
SP7-686DG-IM10-LE • • • • • •
SP8-686DG-IM12-LE
• • • •
Full View 5-Light SL
(6-Light SL - 8'0")
Sidelight
1'0" 1'2"
SP-690DG-CM5-LE
• •
SP7-690DG-CM5-LE
• •
SP-690DG-IM5-LE
• •
SP7-690DG-IM5-LE
• •
SP8-690DG-IM6-LE
• •
690DG-IM5 available as 7/8" muntin
3/4 View 4-Light SL
(5-Light SL - 8'0")
Sidelight
1'0" 1'2"
SP-422DG-IM4-LE • •
SP7-422DG-IM4-LE • •
SP8-422DG-IM5-LE • •
1/2 View 3-Light SL
Sidelight
1'0" 1'2"
SP-692DG-IM3-LE • •
SP7-692DG-IM3-LE • •
11/16" Contoured Internal
Muntin Grille (CM)
5/8" Internal Muntin
Grille (IM)
DIRECT GLAZE
Symbol indicates Smooth-Pro Direct Glaze
doors with a minimum 10" bottom rail to
meet ADA 404.2.10 accessibility guidelines.
Other door styles may be available. Ask your
BROSCO dealer for details.
6'8", 7'0" and 8'0" Doors and Sidelights – Grilles Between Glass (White)
6'8", 7'0" and 8'0" Doors and Sidelights – Blinds Between Glass
Full View
Door
2'0" 2'4" 2'6" 2'8" 2'10" 3'0"
SP-686DG-RLB-LE • • • • • •
SP7-686DG-RLB-LE • • • • • •
SP8-686DG-RLB-LE
• • • •
Full View SL
Sidelight
1'0" 1'2"
SP-690DG-RLB-LE • •
SP7-690DG-RLB-LE • •
SP8-690DG-RLB-LE • •
